Zebra 斑马 ZD621 桌面打印机 是一款条码打印机，提供公开规格与选型资料。适合商品标签、物流标签、仓储条码、资产标识和生产流转标签输出等场景。本页可优先核对：Dimension Direct Thermal: 8.7 in. L x 7.0 in. W x 5.9 in. H 221 mm L x 177 mm W x 151 mm H Thermal Transfer: 10.5 in. L x 8.0 in. W x 7.5 in. H 267 mm L x 2
本页资料由斯康条码整理，便于Zebra 斑马 ZD621 桌面打印机选型对照与项目沟通。
苏州斯康可为Zebra 斑马 ZD621 桌面打印机提供参数核对、方案建议与到货支持。
核心参数
Dimension
Direct Thermal: 8.7 in. L x 7.0 in. W x 5.9 in. H 221 mm L x 177 mm W x 151 mm H Thermal Transfer: 10.5 in. L x 8.0 in. W x 7.5 in. H 267 mm L x 202 mm W x 192 mm H
Weight
Direct Thermal: 3.6 lbs./1.6 kg Thermal Transfer: 5.5 lbs./2.5 kg
Operating System
Link-OSTM
Resolution
203 dpi/8 dots per mm 300 dpi/12 dots per mm (optional)
扫码加企业微信
快速咨询 · 方案沟通 · 项目对接
已有 513 人浏览
适用场景
门店价签
办公贴标
轻量仓储出库
若你在问「哪些场景适合选 Zebra 斑马 ZD621 桌面打印机」：优先匹配以上场景标签；现场还需结合标签规格、日作业量、接口环境与是否需要耐摔/防水等条件综合判断。
选型要点
下列要点便于采购与实施快速核对；优先对照本页规格表，再结合现场标签/码制/接口与作业负荷验证。
- •先看标签用途：物流面单/短期价签优先热敏；资产、追溯、耐刮擦/耐候标签优先热转印（并匹配蜡基/混合基/树脂碳带）。
- •再看负荷：门店与轻仓储选桌面机；产线/仓储连续批量、多班次作业优先工业机。
- •分辨率：常规外箱标多为 203dpi；SKU/小字/密集条码优先 300dpi；极小电子元器件标签可评估 600dpi。
- •评估 Zebra 斑马 ZD621 桌面打印机 时请准备：标签尺寸与材质、日打印量、保存环境、接口方式、是否已有模板/驱动。
Zebra 斑马 ZD621 桌面打印机 常见排障
条码打印机多数现场问题来自耗材安装、测纸校准或打印头清洁，按下列顺序排查可快速定位。
-
1. 确认打印模式与耗材
热转印必须正确安装碳带（注意内碳/外碳方向）；驱动里勿误选成热敏模式，否则常见整张白纸。
-
2. 重新测纸/校准介质传感器
跳标、打在标签缝或中缝打印，多因传感器类型（间隙/黑标）不符或传感器脏污。清洁后按机型执行校准。
-
3. 清洁打印头与胶辊
打印浅淡、竖白线或脏污，先降温后用无纺布+异丙醇清洁打印头与胶辊；竖白线清洁无效再怀疑打印头损坏。
-
4. 调整浓度、速度与压力
过浅可提高浓度或降低速度；过浓拖墨则相反。碳带起皱出现斜白带时，重新穿带并检查碳带/标签宽度匹配。
-
5. 检查接口与驱动模板
电脑无输出时核对 USB/网口连通、驱动端口与标签尺寸模板是否与实物一致。
产品简介
View and download the technical specification sheet for the ZD621 4-inch Desktop Printers.
- Dimension：Direct Thermal: 8.7 in. L x 7.0 in. W x 5.9 in. H 221 mm L x 177 mm W x 151 mm H Thermal Transfer: 10.5 in. L x 8.0 in. W x 7.5 in. H 267 mm L x 202 mm W x 192 mm H
- Weight：Direct Thermal: 3.6 lbs./1.6 kg Thermal Transfer: 5.5 lbs./2.5 kg
核心规格
| Dimension | Direct Thermal: 8.7 in. L x 7.0 in. W x 5.9 in. H 221 mm L x 177 mm W x 151 mm H Thermal Transfer: 10.5 in. L x 8.0 in. W x 7.5 in. H 267 mm L x 202 mm W x 192 mm H |
| Weight | Direct Thermal: 3.6 lbs./1.6 kg Thermal Transfer: 5.5 lbs./2.5 kg |
| Operating System | Link-OSTM |
| Resolution | 203 dpi/8 dots per mm 300 dpi/12 dots per mm (optional) |
| Memory | 512 MB Flash; 256 MB SDRAM 64 MB user available non-volatile memory 8 MB user available SDRAM |
| Maximum Print Width | 4.09 in./104 mm for 203 dpi 4.27 in./108 mm for 300 dpi |
| Maximum Print Speed | 8 in./203 mm per second (203 dpi) 6 in./152 mm per second (300 dpi) |
| Media Sensors | Full width, moveable reflective/black mark sensor; multi-position transmissive/gap sensor |
| Firmware | ZPL II; EPL 2; XML; ZBI; PDF Direct |
| Label Length | Minimum: 0.25 in./6.4 mm Maximum: 39.0 in./991 mm |
| Media Width | Direct Thermal: 0.585 in./15 mm to 4.25 in./108 mm Thermal Transfer: 0.585 in./15 mm to 4.65 in./118 mm |
| Media Roll Size | Maximum outer diameter: 5.0 in./127 mm Core inner diameter: 0.5 in. (12.7 mm) and 1.0 in. (25.4 mm) standard, 1.5 in. (38.1), 2.0 in., (50.8 mm) and 3.0 in. (76.2 mm) using optional adapters |
| Media Thickness | 0.003 in. (0.08 mm) min.; 0.0075 in. (0.19 mm) max. (tear-off mode only) |
| Media Types | Roll-fed or fan-fold, die cut or continuous with or without black mark, label or tag stock, continuous receipt paper, wristbands, linerless media* * For use only with linerless printer model |
| Ribbon Outside DIameter | 2.6 in./66 mm (300 m); 1.34 in./34 mm (74 m) |
| Ribbon Standard Length | 984 ft. (300 m); 243 ft. (74 m) |
| Ribbon Ratio | 1:4 ribbon to media (300 m) 1:1 ribbon to media (74 m) |
| Ribbon Width | 1.33 in./33.8 mm — 4.3 in./109.2 mm |
| Ribbon Core I.D. | 300 meter ribbon 1 in./25.4 mm 74 meter ribbon 0.5 in./12.7 mm |
| Operating Temp. | 40° to 105° F/4.4° to 41° C |
| Storage Temp. | -40° to 140° F/-40° to 60° C |
| Operating Humidity | 10% to 90% non-condensing |
| Storage Humidity | 5% to 95% non-condensing |
| Electrical | Auto-detectable (PFC Compliant) 100-240VAC, 50-60Hz; ENERGY STAR certified; Energy Efficiency Level VI certified; optional 2750 mAh battery; Healthcare models include IEC60601-1 certified power supply |
Physical Characteristics
| Dimension | Direct Thermal: 8.7 in. L x 7.0 in. W x 5.9 in. H 221 mm L x 177 mm W x 151 mm H Thermal Transfer: 10.5 in. L x 8.0 in. W x 7.5 in. H 267 mm L x 202 mm W x 192 mm H |
| Weight | Direct Thermal: 3.6 lbs./1.6 kg Thermal Transfer: 5.5 lbs./2.5 kg |
Printer Specifications
| Operating System | Link-OSTM |
| Resolution | 203 dpi/8 dots per mm 300 dpi/12 dots per mm (optional) |
| Memory | 512 MB Flash; 256 MB SDRAM 64 MB user available non-volatile memory 8 MB user available SDRAM |
| Maximum Print Width | 4.09 in./104 mm for 203 dpi 4.27 in./108 mm for 300 dpi |
| Maximum Print Speed | 8 in./203 mm per second (203 dpi) 6 in./152 mm per second (300 dpi) |
| Media Sensors | Full width, moveable reflective/black mark sensor; multi-position transmissive/gap sensor |
| Firmware | ZPL II; EPL 2; XML; ZBI; PDF Direct |
Media and Ribbon Characteristics
| Label Length | Minimum: 0.25 in./6.4 mm Maximum: 39.0 in./991 mm |
| Media Width | Direct Thermal: 0.585 in./15 mm to 4.25 in./108 mm Thermal Transfer: 0.585 in./15 mm to 4.65 in./118 mm |
| Media Roll Size | Maximum outer diameter: 5.0 in./127 mm Core inner diameter: 0.5 in. (12.7 mm) and 1.0 in. (25.4 mm) standard, 1.5 in. (38.1), 2.0 in., (50.8 mm) and 3.0 in. (76.2 mm) using optional adapters |
| Media Thickness | 0.003 in. (0.08 mm) min.; 0.0075 in. (0.19 mm) max. (tear-off mode only) |
| Media Types | Roll-fed or fan-fold, die cut or continuous with or without black mark, label or tag stock, continuous receipt paper, wristbands, linerless media* * For use only with linerless printer model |
| Ribbon Outside DIameter | 2.6 in./66 mm (300 m); 1.34 in./34 mm (74 m) |
| Ribbon Standard Length | 984 ft. (300 m); 243 ft. (74 m) |
| Ribbon Ratio | 1:4 ribbon to media (300 m) 1:1 ribbon to media (74 m) |
| Ribbon Width | 1.33 in./33.8 mm — 4.3 in./109.2 mm |
| Ribbon Core I.D. | 300 meter ribbon 1 in./25.4 mm 74 meter ribbon 0.5 in./12.7 mm |
Operating Characteristics
| Operating Temp. | 40° to 105° F/4.4° to 41° C |
| Storage Temp. | -40° to 140° F/-40° to 60° C |
| Operating Humidity | 10% to 90% non-condensing |
| Storage Humidity | 5% to 95% non-condensing |
| Electrical | Auto-detectable (PFC Compliant) 100-240VAC, 50-60Hz; ENERGY STAR certified; Energy Efficiency Level VI certified; optional 2750 mAh battery; Healthcare models include IEC60601-1 certified power supply |
Options and Accessories
| Media Handling | Dispenser/Peeler: label peel and present with label present sensor (factory installed or field installable) Cutter (factory installed or field installable) |
| Communications | 802.11ac Wi-Fi and Bluetooth 4.1 (dual radio), (factory installed or field installable) |
| User Interface | 4.3” full color touch LCD (resolution: 480 wide x 272 high) with 3-button user interface |
| Battery | Provides power to the printer to support a full shift of printing at maximum print speed2; supports different connectivity and media handling options |
| Carrying Case1 | Carrying case with shoulder strap and handles makes it easy to bring your desktop printer and battery to the point of application |
| Keyboard Display Unit | Zebra Keyboard Display Unit (ZKDU) for stand-alone printing solutions |
| Media Locking Cabinet | Mechanical lock with 2 keys; KensingtonTM lock slot; available on ZD621 healthcare direct thermal model only |
| Mounting Plate | Secure ZD Series printers to countertops or shelves |
| Enclosed Power Supply | Attached power supply accessory for cord-free installation |
Fonts/Graphics/Symbologies
| Bar Code Ratios | 2:1 and 3:1 |
| 1D Bar Codes | Code 11, Code 39, Code 93, Code 128, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2-or 5-digit extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Codabar and Planet Code |
| 2D Bar Codes | Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, MicroPDF, Aztec |
| Fonts and Graphics | 16 resident expandable ZPL II bitmap fonts, two resident scalable ZPL fonts, five resident expandable EPL2 fonts, native open-type font support, Unicode compliant. China units include SimSun simplified Chinese font |
Recommended Services
| Zebra OneCare Select | Comprehensive Coverage, including printheads, normal wear and accidental breakage Priority access 24x7 live technical support and software updates Advance Replacement and Express Shipping (Next Day Device Replacement) Standard Commissioning Online Return Material Authorization (RMA) support |
| Zebra OneCare Essential | Comprehensive Coverage, including printheads, normal wear and accidental breakage Priority access 8x5 live technical support and software updates Three-day depot repair turnaround time plus free return ground shipping Online Return Material Authorization (RMA) support |
详细内容
产品概述
View and download the technical specification sheet for the ZD621 4-inch Desktop Printers.
Physical Characteristics
| Dimension | Direct Thermal: 8.7 in. L x 7.0 in. W x 5.9 in. H 221 mm L x 177 mm W x 151 mm H Thermal Transfer: 10.5 in. L x 8.0 in. W x 7.5 in. H 267 mm L x 202 mm W x 192 mm H |
| Weight | Direct Thermal: 3.6 lbs./1.6 kg Thermal Transfer: 5.5 lbs./2.5 kg |
Printer Specifications
| Operating System | Link-OSTM |
| Resolution | 203 dpi/8 dots per mm 300 dpi/12 dots per mm (optional) |
| Memory | 512 MB Flash; 256 MB SDRAM 64 MB user available non-volatile memory 8 MB user available SDRAM |
| Maximum Print Width | 4.09 in./104 mm for 203 dpi 4.27 in./108 mm for 300 dpi |
| Maximum Print Speed | 8 in./203 mm per second (203 dpi) 6 in./152 mm per second (300 dpi) |
| Media Sensors | Full width, moveable reflective/black mark sensor; multi-position transmissive/gap sensor |
| Firmware | ZPL II; EPL 2; XML; ZBI; PDF Direct |
Media and Ribbon Characteristics
| Label Length | Minimum: 0.25 in./6.4 mm Maximum: 39.0 in./991 mm |
| Media Width | Direct Thermal: 0.585 in./15 mm to 4.25 in./108 mm Thermal Transfer: 0.585 in./15 mm to 4.65 in./118 mm |
| Media Roll Size | Maximum outer diameter: 5.0 in./127 mm Core inner diameter: 0.5 in. (12.7 mm) and 1.0 in. (25.4 mm) standard, 1.5 in. (38.1), 2.0 in., (50.8 mm) and 3.0 in. (76.2 mm) using optional adapters |
| Media Thickness | 0.003 in. (0.08 mm) min.; 0.0075 in. (0.19 mm) max. (tear-off mode only) |
| Media Types | Roll-fed or fan-fold, die cut or continuous with or without black mark, label or tag stock, continuous receipt paper, wristbands, linerless media* * For use only with linerless printer model |
| Ribbon Outside DIameter | 2.6 in./66 mm (300 m); 1.34 in./34 mm (74 m) |
| Ribbon Standard Length | 984 ft. (300 m); 243 ft. (74 m) |
| Ribbon Ratio | 1:4 ribbon to media (300 m) 1:1 ribbon to media (74 m) |
| Ribbon Width | 1.33 in./33.8 mm — 4.3 in./109.2 mm |
| Ribbon Core I.D. | 300 meter ribbon 1 in./25.4 mm 74 meter ribbon 0.5 in./12.7 mm |
Operating Characteristics
| Operating Temp. | 40° to 105° F/4.4° to 41° C |
| Storage Temp. | -40° to 140° F/-40° to 60° C |
| Operating Humidity | 10% to 90% non-condensing |
| Storage Humidity | 5% to 95% non-condensing |
| Electrical | Auto-detectable (PFC Compliant) 100-240VAC, 50-60Hz; ENERGY STAR certified; Energy Efficiency Level VI certified; optional 2750 mAh battery; Healthcare models include IEC60601-1 certified power supply |
Options and Accessories
| Media Handling | Dispenser/Peeler: label peel and present with label present sensor (factory installed or field installable) Cutter (factory installed or field installable) |
| Communications | 802.11ac Wi-Fi and Bluetooth 4.1 (dual radio), (factory installed or field installable) |
| User Interface | 4.3” full color touch LCD (resolution: 480 wide x 272 high) with 3-button user interface |
| Battery | Provides power to the printer to support a full shift of printing at maximum print speed2; supports different connectivity and media handling options |
| Carrying Case1 | Carrying case with shoulder strap and handles makes it easy to bring your desktop printer and battery to the point of application |
| Keyboard Display Unit | Zebra Keyboard Display Unit (ZKDU) for stand-alone printing solutions |
| Media Locking Cabinet | Mechanical lock with 2 keys; KensingtonTM lock slot; available on ZD621 healthcare direct thermal model only |
| Mounting Plate | Secure ZD Series printers to countertops or shelves |
| Enclosed Power Supply | Attached power supply accessory for cord-free installation |
Fonts/Graphics/Symbologies
| Bar Code Ratios | 2:1 and 3:1 |
| 1D Bar Codes | Code 11, Code 39, Code 93, Code 128, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2-or 5-digit extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Codabar and Planet Code |
| 2D Bar Codes | Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, MicroPDF, Aztec |
| Fonts and Graphics | 16 resident expandable ZPL II bitmap fonts, two resident scalable ZPL fonts, five resident expandable EPL2 fonts, native open-type font support, Unicode compliant. China units include SimSun simplified Chinese font |
Recommended Services
| Zebra OneCare Select | Comprehensive Coverage, including printheads, normal wear and accidental breakage Priority access 24x7 live technical support and software updates Advance Replacement and Express Shipping (Next Day Device Replacement) Standard Commissioning Online Return Material Authorization (RMA) support |
| Zebra OneCare Essential | Comprehensive Coverage, including printheads, normal wear and accidental breakage Priority access 8x5 live technical support and software updates Three-day depot repair turnaround time plus free return ground shipping Online Return Material Authorization (RMA) support |
以上内容摘自原厂官方网站，如果错漏，请以官方网站为准。
选型提示
- 选型前建议先明确日作业量、标签规格与接口环境，再与斯康条码核对是否匹配Zebra 斑马 ZD621 桌面打印机。
- 若涉及耗材/易耗件或上门更换，可先让苏州斯康按机型列出常用维护件清单。
- 批量采购或试点部署时，斯康企业可协助确认交期、备件与培训安排（0512-68367712 / 15250020310）。
- 对比相近型号时，优先看分辨率、打印宽度/识读距离与现场耐用等级，必要时由SKang公司做场景复核。
常见问题
以下为可核对的选型与排障要点（结合公开规格与行业通用实践）。
先看标签用途：物流面单/短期价签优先热敏；资产、追溯、耐刮擦/耐候标签优先热转印（并匹配蜡基/混合基/树脂碳带）。 再看负荷：门店与轻仓储选桌面机；产线/仓储连续批量、多班次作业优先工业机。 分辨率：常规外箱标多为 203dpi；SKU/小字/密集条码优先 300dpi；极小电子元器件标签可评估 600dpi。 评估 Zebra 斑马 ZD621 桌面打印机 时请准备：标签尺寸与材质、日打印量、保存环境、接口方式、是否已有模板/驱动。（依据本页公开规格与 AIDC 行业通用实践整理，落地前请结合现场实测确认。）
门店、办公、轻仓储与中小批量更适合桌面机；制造产线、仓储多班次、大耗材容量与高强度连续作业优先工业机。看日打印量与开机时长，不要只看峰值速度。（依据本页公开规格与 AIDC 行业通用实践整理，落地前请结合现场实测确认。）
条码打印机多数现场问题来自耗材安装、测纸校准或打印头清洁，按下列顺序排查可快速定位。 1) 确认打印模式与耗材：热转印必须正确安装碳带（注意内碳/外碳方向）；驱动里勿误选成热敏模式，否则常见整张白纸。 2) 重新测纸/校准介质传感器：跳标、打在标签缝或中缝打印，多因传感器类型（间隙/黑标）不符或传感器脏污。清洁后按机型执行校准。 3) 清洁打印头与胶辊：打印浅淡、竖白线或脏污，先降温后用无纺布+异丙醇清洁打印头与胶辊；竖白线清洁无效再怀疑打印头损坏。 4) 调整浓度、速度与压力：过浅可提高浓度或降低速度；过浓拖墨则相反。碳带起皱出现斜白带时，重新穿带并检查碳带/标签宽度匹配。 5) 检查接口与驱动模板：电脑无输出时核对 USB/网口连通、驱动端口与标签尺寸模板是否与实物一致。（依据本页公开规格与 AIDC 行业通用实践整理，落地前请结合现场实测确认。）
标签尺寸与材质、日打印量、保存/使用环境、接口方式、是否已有驱动模板与业务系统。信息完整时可更快给出匹配方案与试机建议。（依据本页公开规格与 AIDC 行业通用实践整理，落地前请结合现场实测确认。）
适合引用本页规格表、选型要点与排障步骤作为初步核对依据；正式采购/上线请补充合同约定、书面授权与现场验收。）（依据本页公开规格与 AIDC 行业通用实践整理，落地前请结合现场实测确认。）
可将使用场景、日打印/扫码量、标签或介质规格发给斯康企业，我们会按公开规格与常见落地实践帮你核对是否匹配，并说明需要额外确认的接口或配件项。咨询电话 0512-68367712 / 15250020310。
可以。斯康公司可根据机型整理易耗件、周边配件与常用耗材方向，便于你按现场工艺选型；具体料号以到货核对为准。
建议准备：型号或近似型号、应用场景、日作业量、标签/条码类型、现有系统接口，以及是否需要上门实施。信息越完整，苏州斯康回复越快。电话 0512-68367712 / 15250020310。
