Zebra 斑马 ET80 坚固型平板电脑
View and download the technical specification sheet for the ET80/ET85 Rugged 2-in-1 Tablet.
核心参数
Form Factor
2-in-1 rugged tablet with friction hinge rugged keyboard option (up to 120° opening angle)
Dimensions
Tablet: 12.1 in. W x 8.9 in. L x 0.6 in. H 308 mm W x 225 mm L x 16 mm H Tablet with keyboard: 12.1 in. W x 9.6 L in. x 1.1 in. H 308 mm W x 244 mm L x 29 mm H
Weight
Tablet (with standard battery): 2.8 lbs/1.3 kg Keyboard: 1.85 lbs/0.84 kg
Display
12 in. 3:2 QHD (2160 x 1440) — 800 nits Sunlight readable Corning Gorilla Glass Anti-reflective (AR)/Anti-Smudge screen treatment Night-vision mode
扫码加企业微信
快速咨询 · 方案沟通 · 项目对接
已有 1379 人浏览
适用场景
企业标识
条码打印
数据采集
产品简介
View and download the technical specification sheet for the ET80/ET85 Rugged 2-in-1 Tablet.
- Form Factor：2-in-1 rugged tablet with friction hinge rugged keyboard option (up to 120° opening angle)
- Dimensions：Tablet: 12.1 in. W x 8.9 in. L x 0.6 in. H 308 mm W x 225 mm L x 16 mm H Tablet with keyboard: 12.1 in. W x 9.6 L in. x 1.1 in. H 308 mm W x 244 mm L x 29 mm H
- Weight：Tablet (with standard battery): 2.8 lbs/1.3 kg Keyboard: 1.85 lbs/0.84 kg
- Display：12 in. 3:2 QHD (2160 x 1440) — 800 nits Sunlight readable Corning Gorilla Glass Anti-reflective (AR)/Anti-Smudge screen treatment Night-vision mode
- Touchpanel：Capacitive 10-point multi-touch; Glove and Wet modes; MPP 2.0 active pen compatible
- SIM Slots：ET85 configurations only: Two SIM: (1) Nano SIM (4FF) and (1) eSIM
核心规格
| Form Factor | 2-in-1 rugged tablet with friction hinge rugged keyboard option (up to 120° opening angle) |
| Dimensions | Tablet: 12.1 in. W x 8.9 in. L x 0.6 in. H 308 mm W x 225 mm L x 16 mm H Tablet with keyboard: 12.1 in. W x 9.6 L in. x 1.1 in. H 308 mm W x 244 mm L x 29 mm H |
| Weight | Tablet (with standard battery): 2.8 lbs/1.3 kg Keyboard: 1.85 lbs/0.84 kg |
| Display | 12 in. 3:2 QHD (2160 x 1440) — 800 nits Sunlight readable Corning Gorilla Glass Anti-reflective (AR)/Anti-Smudge screen treatment Night-vision mode |
| Touchpanel | Capacitive 10-point multi-touch; Glove and Wet modes; MPP 2.0 active pen compatible |
| SIM Slots | ET85 configurations only: Two SIM: (1) Nano SIM (4FF) and (1) eSIM |
| Interface Ports and Expansion | (1) USB-C USB 3.2 Gen2, USB-PD charging, USB DisplayPort (2) USB 3.2 Gen2 Type A ports Expansion connector for available 10/100/1000 Ethernet and DB9 true serial ports WWAN, WLAN and GNSS Antenna pass through Keyboard and docking connectors Optional docking solution may be configured with: (4) USB Type A (2) HDMI Type A (3) Ethernet RJ45, power in |
| Notifications | Charging, camera and battery indicators |
| Audio | Stereo front facing speakers; (2) front facing microphones; (2) rear facing microphones; audio headset supported in USB-C and USB-A ports |
| Buttons | Volume up/down button; power on/off button; barcode scanner button (user definable in configurations without the barcode reader) |
| Keyboard | Available detachable friction hinge rugged keyboard with standard sized keys; precision multitouch touchpad with two physical click buttons; adjustable color backlighting; waterproof IP65; (6) programmable keys including emergency key |
| CPU | 11th generation Intel™ Core™ i7-1180G7 vPro™ processor 11th generation Intel™ Core™ i5-1140G7 vPro™ processor 11th generation Intel™ Core™ i5-1130G7 processor |
| Operating System | Windows™ 11 Professional 64-bit |
| Memory | 8 GB or 16 GB LPDDR4x-4266 |
| Storage | 128 GB, 256 GB or 512 GB tool-less user removable PCIe SSD |
Physical Characteristics
| Form Factor | 2-in-1 rugged tablet with friction hinge rugged keyboard option (up to 120° opening angle) |
| Dimensions | Tablet: 12.1 in. W x 8.9 in. L x 0.6 in. H 308 mm W x 225 mm L x 16 mm H Tablet with keyboard: 12.1 in. W x 9.6 L in. x 1.1 in. H 308 mm W x 244 mm L x 29 mm H |
| Weight | Tablet (with standard battery): 2.8 lbs/1.3 kg Keyboard: 1.85 lbs/0.84 kg |
| Display | 12 in. 3:2 QHD (2160 x 1440) — 800 nits Sunlight readable Corning Gorilla Glass Anti-reflective (AR)/Anti-Smudge screen treatment Night-vision mode |
| Touchpanel | Capacitive 10-point multi-touch; Glove and Wet modes; MPP 2.0 active pen compatible |
| SIM Slots | ET85 configurations only: Two SIM: (1) Nano SIM (4FF) and (1) eSIM |
| Interface Ports and Expansion | (1) USB-C USB 3.2 Gen2, USB-PD charging, USB DisplayPort (2) USB 3.2 Gen2 Type A ports Expansion connector for available 10/100/1000 Ethernet and DB9 true serial ports WWAN, WLAN and GNSS Antenna pass through Keyboard and docking connectors Optional docking solution may be configured with: (4) USB Type A (2) HDMI Type A (3) Ethernet RJ45, power in |
| Notifications | Charging, camera and battery indicators |
| Audio | Stereo front facing speakers; (2) front facing microphones; (2) rear facing microphones; audio headset supported in USB-C and USB-A ports |
| Buttons | Volume up/down button; power on/off button; barcode scanner button (user definable in configurations without the barcode reader) |
| Keyboard | Available detachable friction hinge rugged keyboard with standard sized keys; precision multitouch touchpad with two physical click buttons; adjustable color backlighting; waterproof IP65; (6) programmable keys including emergency key |
Performance Characteristics
| CPU | 11th generation Intel™ Core™ i7-1180G7 vPro™ processor 11th generation Intel™ Core™ i5-1140G7 vPro™ processor 11th generation Intel™ Core™ i5-1130G7 processor |
| Operating System | Windows™ 11 Professional 64-bit |
| Memory | 8 GB or 16 GB LPDDR4x-4266 |
| Storage | 128 GB, 256 GB or 512 GB tool-less user removable PCIe SSD |
User Environment
| Operating Temp. | -4° F to 140° F/-20° C to 60° C |
| Storage Temp. | -22° F to 158° F/-30° C to 70° C |
| Humidity | 5% to 95% non-condensing |
| Drop Specifications | MIL-STD-810H drop to plywood over concrete Standard: 4 ft./1.2 m With optional rugged boot: 5 ft./1.5 m With keyboard: 3 ft./0.9 m |
| Sealing | IEC 60529 Clause 13.4 enclosures; IP65 for tablet with ports open, keyboard and dock |
| Vibration | Operational: MIL-STD-810H 514.8 Composite Wheel; Non-Operating: MIL-STD-810H 514.8 E-1 |
| Electromagnetic Compatibility | MIL-STD 461G; EN 55032; EN 55024 |
| Thermal Shock | MIL-STD-810H 503.7 -4° F to 140° F/-20° C to 60° C (operating); -22° F to 158° F/-30° C to 70° C (non-operating) |
| Electrostatic Discharge | IEC61000-4-2; ± 15kV air discharge; ± 8 kV contact |
| Shock | MIL-STD-810H Method 516.8, Procedure I; 20 g operating, 40 g non-operating |
| Solar Radiation | MIL-STD 810H 505.7 |
| Contamination by Fluids | MIL-STD-810H, Method 504.3 |
| Approved Cleaning and Disinfecting Agents | Mild dish soap, 70% Isopropyl Alcohol solution, 0.5-3% Hydrogen Peroxide solution, 1:10 Diluted 5.5% Bleach (Sodium Hypochlorite) solution3 |
| Hazardous Location Certification | C1D2 tablet configurations and compliant keyboards available |
| Certifications | EPEAT, Energy Star, EU CoC |
| Vehicle certifications | E-Mark Europe 12V system ECE Regulation No.10 Rev 6 (Tablet with keyboard in docking station) No external DC to DC converter required for 12 volt automobile systems |
Power
| Battery | 5180 mAhr, 7.7V rechargeable Li-Polymer; user replaceable (39.8 Whr) Time to full charge 2.5 hours Optional hot swappable 3400mAh, 7.6V (25.8 Whr) secondary battery (expansion back required) 45W USB-PD (type C) AC adapter sold separately |
Sensors
| Ambient Light Sensor | Automatically adjusts display attributes and keyboard backlight |
| Magnetometer | 3-axis e-compass |
| Motion Sensor | 3-axis gyroscope; 3-axis accelerometer |
Data Capture
| Scanning | SE4107 2D scanner (available option) |
| Rear Camera | 13 MP auto-focus camera with user controllable LED flash; mechanical privacy shade |
| Front Camera | FHD Windows Hello auto-focus camera; mechanical privacy shade |
| Video | Intel Gen 12 Gfx with 4 display pipes and 8K Intel wireless display External display support: DP 1.2 up to 4096 x 2160 px, 60Hz; dock supports (2) HDMI 1080p displays |
Wireless Communications
| WiFi (WLAN) | WiFi 6E1, 802.11ax R2 including the new 6 Ghz band, 2x2 MIMO; 802.11a/b/g/n/ac R2/ax R2, WPA, WPA2, WPA3, WPS, PMF, WMM, WMM-PS, WFD, WiFi Agile Multiband, WiFi Optimized Connectivity, WiFi Location, WiFi TimeSync |
| Cellular (WWAN) | ET85 configurations required: available 5G (support for 3 GPP Rel 15 including Cat 22 LTE, 3G, and sub 6 GHz NR) data only or Global LTE Category 12 data only |
| Bluetooth (WPAN) | Bluetooth 5.1 + Audio LE, Class 1 |
| GPS | ET85 configurations required: GPS, GLONASS, BeiDou/Compass, Galileo. Dual band (L1 + L5) with aGPS (support varies by carrier) |
| NFC | Supports NFC peer to peer, card reader/writer and card emulation modes; P2P: ISO/IEC 18092; Reader/Writer: ISO 14443 –A-B, MIFARE, FeliCa™, ISO 15693, NFC Forum Tag Types 1 to 4; Card emulation: ISO 14443 – A-B-B’, MIFARE, FeliCa RF |
详细内容
产品概述
View and download the technical specification sheet for the ET80/ET85 Rugged 2-in-1 Tablet.
Physical Characteristics
| Form Factor | 2-in-1 rugged tablet with friction hinge rugged keyboard option (up to 120° opening angle) |
| Dimensions | Tablet: 12.1 in. W x 8.9 in. L x 0.6 in. H 308 mm W x 225 mm L x 16 mm H Tablet with keyboard: 12.1 in. W x 9.6 L in. x 1.1 in. H 308 mm W x 244 mm L x 29 mm H |
| Weight | Tablet (with standard battery): 2.8 lbs/1.3 kg Keyboard: 1.85 lbs/0.84 kg |
| Display | 12 in. 3:2 QHD (2160 x 1440) — 800 nits Sunlight readable Corning Gorilla Glass Anti-reflective (AR)/Anti-Smudge screen treatment Night-vision mode |
| Touchpanel | Capacitive 10-point multi-touch; Glove and Wet modes; MPP 2.0 active pen compatible |
| SIM Slots | ET85 configurations only: Two SIM: (1) Nano SIM (4FF) and (1) eSIM |
| Interface Ports and Expansion | (1) USB-C USB 3.2 Gen2, USB-PD charging, USB DisplayPort (2) USB 3.2 Gen2 Type A ports Expansion connector for available 10/100/1000 Ethernet and DB9 true serial ports WWAN, WLAN and GNSS Antenna pass through Keyboard and docking connectors Optional docking solution may be configured with: (4) USB Type A (2) HDMI Type A (3) Ethernet RJ45, power in |
| Notifications | Charging, camera and battery indicators |
| Audio | Stereo front facing speakers; (2) front facing microphones; (2) rear facing microphones; audio headset supported in USB-C and USB-A ports |
| Buttons | Volume up/down button; power on/off button; barcode scanner button (user definable in configurations without the barcode reader) |
| Keyboard | Available detachable friction hinge rugged keyboard with standard sized keys; precision multitouch touchpad with two physical click buttons; adjustable color backlighting; waterproof IP65; (6) programmable keys including emergency key |
Performance Characteristics
| CPU | 11th generation Intel™ Core™ i7-1180G7 vPro™ processor 11th generation Intel™ Core™ i5-1140G7 vPro™ processor 11th generation Intel™ Core™ i5-1130G7 processor |
| Operating System | Windows™ 11 Professional 64-bit |
| Memory | 8 GB or 16 GB LPDDR4x-4266 |
| Storage | 128 GB, 256 GB or 512 GB tool-less user removable PCIe SSD |
User Environment
| Operating Temp. | -4° F to 140° F/-20° C to 60° C |
| Storage Temp. | -22° F to 158° F/-30° C to 70° C |
| Humidity | 5% to 95% non-condensing |
| Drop Specifications | MIL-STD-810H drop to plywood over concrete Standard: 4 ft./1.2 m With optional rugged boot: 5 ft./1.5 m With keyboard: 3 ft./0.9 m |
| Sealing | IEC 60529 Clause 13.4 enclosures; IP65 for tablet with ports open, keyboard and dock |
| Vibration | Operational: MIL-STD-810H 514.8 Composite Wheel; Non-Operating: MIL-STD-810H 514.8 E-1 |
| Electromagnetic Compatibility | MIL-STD 461G; EN 55032; EN 55024 |
| Thermal Shock | MIL-STD-810H 503.7 -4° F to 140° F/-20° C to 60° C (operating); -22° F to 158° F/-30° C to 70° C (non-operating) |
| Electrostatic Discharge | IEC61000-4-2; ± 15kV air discharge; ± 8 kV contact |
| Shock | MIL-STD-810H Method 516.8, Procedure I; 20 g operating, 40 g non-operating |
| Solar Radiation | MIL-STD 810H 505.7 |
| Contamination by Fluids | MIL-STD-810H, Method 504.3 |
| Approved Cleaning and Disinfecting Agents | Mild dish soap, 70% Isopropyl Alcohol solution, 0.5-3% Hydrogen Peroxide solution, 1:10 Diluted 5.5% Bleach (Sodium Hypochlorite) solution3 |
| Hazardous Location Certification | C1D2 tablet configurations and compliant keyboards available |
| Certifications | EPEAT, Energy Star, EU CoC |
| Vehicle certifications | E-Mark Europe 12V system ECE Regulation No.10 Rev 6 (Tablet with keyboard in docking station) No external DC to DC converter required for 12 volt automobile systems |
Power
| Battery | 5180 mAhr, 7.7V rechargeable Li-Polymer; user replaceable (39.8 Whr) Time to full charge 2.5 hours Optional hot swappable 3400mAh, 7.6V (25.8 Whr) secondary battery (expansion back required) 45W USB-PD (type C) AC adapter sold separately |
Sensors
| Ambient Light Sensor | Automatically adjusts display attributes and keyboard backlight |
| Magnetometer | 3-axis e-compass |
| Motion Sensor | 3-axis gyroscope; 3-axis accelerometer |
Data Capture
| Scanning | SE4107 2D scanner (available option) |
| Rear Camera | 13 MP auto-focus camera with user controllable LED flash; mechanical privacy shade |
| Front Camera | FHD Windows Hello auto-focus camera; mechanical privacy shade |
| Video | Intel Gen 12 Gfx with 4 display pipes and 8K Intel wireless display External display support: DP 1.2 up to 4096 x 2160 px, 60Hz; dock supports (2) HDMI 1080p displays |
Wireless Communications
| WiFi (WLAN) | WiFi 6E1, 802.11ax R2 including the new 6 Ghz band, 2x2 MIMO; 802.11a/b/g/n/ac R2/ax R2, WPA, WPA2, WPA3, WPS, PMF, WMM, WMM-PS, WFD, WiFi Agile Multiband, WiFi Optimized Connectivity, WiFi Location, WiFi TimeSync |
| Cellular (WWAN) | ET85 configurations required: available 5G (support for 3 GPP Rel 15 including Cat 22 LTE, 3G, and sub 6 GHz NR) data only or Global LTE Category 12 data only |
| Bluetooth (WPAN) | Bluetooth 5.1 + Audio LE, Class 1 |
| GPS | ET85 configurations required: GPS, GLONASS, BeiDou/Compass, Galileo. Dual band (L1 + L5) with aGPS (support varies by carrier) |
| NFC | Supports NFC peer to peer, card reader/writer and card emulation modes; P2P: ISO/IEC 18092; Reader/Writer: ISO 14443 –A-B, MIFARE, FeliCa™, ISO 15693, NFC Forum Tag Types 1 to 4; Card emulation: ISO 14443 – A-B-B’, MIFARE, FeliCa RF |
